Fibre Pigtails, LCA OS2, 2m Length - 12 Pack
The CERTECH LCA OS2 Fibre Pigtails are single-mode LC/APC pigtails designed for fusion splicing into distribution frames, patch panels, and splice enclosures. Supplied in a 12-pack with 2m yellow OS2 jacketed tails — ready for high-density fibre terminations in data centres, commercial buildings, and telecommunications infrastructure.
| Single-Mode OS2 | LC/APC Connector | 12 Pack |
Specifications
| Connector Type | LC/APC (LC Angled Physical Contact) |
| Fibre Type | OS2 Single-Mode, 9/125µm |
| Wavelength | 1310nm / 1550nm |
| Insertion Loss | ≤0.3 dB |
| Return Loss (APC) | ≥60 dB |
| Jacket Length | 2 metres |
| Jacket Colour | Yellow (OS2 standard) |
| Pack Quantity | 12 pigtails |
Key Features
LC/APC Angled Connector — Ultra-Low Reflectance
The angled physical contact (APC) polish delivers return loss of 60dB or greater, making these pigtails ideal for GPON, FTTx, and analogue video systems where back-reflections cause signal degradation.
OS2 Single-Mode Fibre — Long-Haul Ready
9/125µm single-mode fibre supports both 1310nm and 1550nm wavelengths with low attenuation — suitable for backbone runs, inter-building links, and carrier-grade installations.
2m Tail Length — Flexible Routing
The 2 metre pigtail provides enough slack for neat routing inside a splice enclosure or patch panel tray without excessive coiling that can introduce bend losses.
12-Pack — Efficient High-Density Termination
Sold in packs of 12 to match a standard fibre cassette or splice tray capacity, reducing ordering overhead on multi-port termination jobs.
- LC/APC connector with ≥60dB return loss for GPON and FTTx applications
- OS2 single-mode 9/125µm fibre supporting 1310nm and 1550nm wavelengths
- 2 metre tail length for flexible routing inside enclosures and patch trays
- 12-pack quantity matches standard splice tray capacity
- Insertion loss ≤0.3dB for reliable signal transmission
- Yellow OS2 jacket — compliant with TIA-598 colour coding standards
