Fibre Pigtails, SCA OS2, 2m Length - 12 Pack
The CERTECH SCA OS2 Fibre Pigtails are single-mode SC/APC pigtails built for fusion splicing into splice enclosures, distribution frames, and fibre patch panels. Supplied in a 12-pack with 2m yellow OS2 jacketed tails — the go-to choice for GPON, PON, and outside-plant terminations where the SC connector is the field standard.
| Single-Mode OS2 | SC/APC Connector | 12 Pack |
Specifications
| Connector Type | SC/APC (SC Angled Physical Contact) |
| Fibre Type | OS2 Single-Mode, 9/125µm |
| Wavelength | 1310nm / 1550nm |
| Insertion Loss | ≤0.3 dB |
| Return Loss (APC) | ≥60 dB |
| Jacket Length | 2 metres |
| Jacket Colour | Yellow (OS2 standard) |
| Pack Quantity | 12 pigtails |
Key Features
SC/APC Connector — GPON and PON Field Standard
The SC push-pull connector is the dominant choice in Australian NBN, GPON, and outside-plant networks. The APC (8° angled) polish suppresses back-reflections to ≥60dB — essential for PON architectures where reflected light can disrupt upstream signals across multiple subscribers.
OS2 Single-Mode Fibre — Long-Distance Performance
9/125µm single-mode fibre with low attenuation at both 1310nm and 1550nm wavelengths. Suited for backbone interconnects, inter-building links, and carrier infrastructure where multimode fibre reaches its distance limits.
2m Tail Length — Clean Splice Tray Routing
The 2 metre pigtail provides enough length to route neatly through a splice enclosure while leaving sufficient slack for re-splicing if a joint needs to be redone — without having to replace the pigtail.
12-Pack — One Box Per Splice Tray
12 pigtails per pack aligns with standard 12-fibre splice tray and cassette capacity, letting you complete a full tray in one order without off-cuts or leftover stock.
- SC/APC connector with ≥60dB return loss — GPON, NBN, and PON network standard
- OS2 single-mode 9/125µm fibre supporting 1310nm and 1550nm wavelengths
- 2 metre tail length provides routing slack and re-splice allowance
- 12-pack quantity matches standard 12-fibre splice tray capacity
- Insertion loss ≤0.3dB for reliable long-distance signal transmission
- Yellow OS2 jacket — TIA-598 compliant colour coding for single-mode fibre
